Product Details:
|
Material: | Aviation Grade Aluminum Alloy | Function: | Video Transmission; Data Transmission; Remote Control;video Display; Industrial Garde Computer Function |
---|---|---|---|
Application: | Controlling UAV,UGV,USV,etc |
GCS T40 | |||
Overall weight | 5980g | Dimension | 354mm(L)*280mm(W)*80mm(H) |
Battery capacity |
16.8V/13600mAh (external battery also supported) |
Endurance | 3h@full battery capacity |
Physical channel | 27 | Touch pad | 10-finger capacitive touch screen |
(industrial joysticks with hall sensors)
|
Display screen |
13.3inch 1920*1080 1000CCD (top screen) 12.1inch 1280*800 1500CCD (bottom screen) |
|
CPU | Intel i7 8565U/10500U | ROM | 8GB |
Operating system | Win7/win10/Linux | Storage | 256GB |
SBUS | Dual SBUS independent output,HID input | Touch panel | Capacitive 10-finger multi-touch display |
Video system | Built in | Network | WIFI, Bluetooth(standard)/4G(optional) |
Channel | 27 physical channels | External interface | USB3.0,LAN,HDMI in,VGA out,Hi-fi |
Remote control latency | 30ms | Serial port | RS232*3,SBUS out/in |
Antenna | 4dB rod antenna/10dBi fibre-glass epoxy antenna(other antennas also can be connected externally) | Power supply interface | DC16.8V |
Remote control range | 5km-20km | Operation temperature | -20~+60℃ |
RF power | V20:0.1-1w(adjustable) V21:0.1-1w(adjustable) V30:0.1-1w(adjustable) | Dimension | 354mmL*280mmW*80mmH |
Frequency | 800MHZ/902-920MHZ 1.4Ghz/2.3Ghz/2.4Ghz/2.5Ghz | Overall weight | 5980g |
Aviation grade aluminum shell,the overall weight only 5.98kg
Dual touch screens with high definition and brightness and extended touch pad
Programmable channels,supporting traditional RC access
Add HID USB and programmable switches that can be set in the software
Compatible with 100% data link in the market
